Manufacturer: DiversiTech Corporation
Brand: Packard
Part #: 385818
MPN: C340A
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
Amperage Rating      :      40 A
Coil Voltage      :      24 VAC
Connection Type      :      Box Lug, Spade Terminal
Contact Material      :      Silver Plated
Contact Rating      :      40 A (Inductive, 600 VAC), 50 A (Resistive, 600 VAC)
Expansion Slot Type      :      Accepts Auxiliary Switch
Frequency Rating      :      50 Hz, 60 Hz
Full Load Current Rating      :      40 A
Insulation Class      :      Class B (Coil)
Load Rating      :      40 A (Inductive), 50 A (Resistive)
Locked Rotor Rating      :      240 A (240/277 V), 200 A (480 V), 160 A (600 V)
Model      :      C340A
Mounting Type      :      Foot Mount
Number of Poles      :      3
Operating Cycles      :      250,000 cycles
Resistive Amperage      :      50 A
Terminal Type      :      Box Lug, Spade Terminal
Voltage Rating      :      600 VAC

In accordance with U.L. Bulletin No. 508 "Industrial Control Equipment", contactors meet specifications for devices up to 600 VAC.Coils have class B insulation.Includes Lug, spade terminals, and covers.

Packard Definite Purpose Contactor, 3 Pole, 40 A (Inductive, 600 VAC), 50 A (Resistive, 600 VAC) Contact Rating, 24 VAC, 600 VAC, 240 A (240/277 V), 200 A (480 V), 160 A (600 V), Box Lug, Spade Terminal Connection Type, Foot Mount, Silver Plated Contacts, 50 Hz, 60 Hz, 250,000 Cycles, Class B (Coil), Accepts Auxiliary Switch

  • Meets UL 508 specifications for devices rated up to 600 VAC.
  • Features reliable Class B coil insulation.
  • Rated for 3-pole switching with 40A inductive and 50A resistive capacity.
  • Includes box lug terminals, spade terminals, and protective covers for connection flexibility.
  • Designed with a versatile foot mount for easy installation.
  • Accepts Packard auxiliary switches (AC3/P6S/P7S) for additional control options.
  • UL recognized and CSA certified.
