Water Furnace Aston Advanced 161K049TR141N00D0 Geothermal Heat Pump, 4 Tons, R-410A, Vertical, Upflow, Right Hand, 208/230 V, 17.2-24.5 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase
Water Furnace Aston Advanced 161K049TR141N00D0 Geothermal Heat Pump, 4 Tons, R-410A, Vertical, Upflow, Right Hand, 208/230 V, 17.2-24.5 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase
| Amperage Rating | : | 34.5 A (FLA), 39.8 A (MCA) |
| BTU Rating | : | 49,000 BTU/hr |
| Blower Size | : | 9" Diam x 7" W |
| CFM Rating | : | 1,600 CFM |
| Coil Rating | : | 4 Tons |
| Color | : | Off White |
| Compressor Type | : | Dual Capacity Scroll |
| Configuration | : | Vertical, Upflow, Right Hand |
| Connection Type | : | 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) |
| Dimensions | : | 54-2/5" H x 25-3/5" W x 31-3/5" D |
| Drive Type | : | Direct Drive |
| EER Rating | : | 17.2-24.5 EER |
| Filter Size | : | 32" x 30" x 2" |
| Finish | : | Powder Coated (1,000 Hour Salt Spray Rated) |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 60 A |
| HP Rating | : | 1 HP (Blower Motor) |
| Material | : | Galvanized Steel (Cabinet), Copper (Coil Inner Tube), Steel (Coil Outer Tube) |
| Model | : | 161K049TR141N00D0 |
| Mounting Type | : | Vertical Upflow |
| Number of Stages | : | 2 |
| Phase | : | 1 |
| Pressure Rating | : | 464.7 PSI (Working Water), 614.7 PSI (Working Refrigerant) |
| Refrigerant Type | : | R-410A |
| Series | : | Aston Advanced |
| Temperature Rating | : | 50-110 °F (Entering Air, Cooling), 40-80 °F (Entering Air, Heating), 30-120 °F (Entering Water) |
| Tonnage | : | 4 tons |
| Voltage Rating | : | 208/230 V |
The Aston Advanced Series ground source heat pump provides efficient heating and cooling in a vertical upflow package configuration with right-hand return air. This 4-ton unit operates on 208/230V, single-phase power and is designed for reliable geothermal performance.Equipped with a Copeland UltraTech dual-capacity scroll compressor and a 1 HP variable-speed ECM direct-drive blower motor, this unit delivers adaptable comfort and efficiency, achieving EER ratings up to 24.5. It utilizes R-410A refrigerant and features durable galvanized steel cabinet construction with a corrosion-resistant powder coat finish.
Water Furnace Geothermal Heat Pump, Model: Aston Advanced, 4 Tons, R-410A, Vertical, Upflow, Right Hand, 208/230 V, 17.2-24.5 EER, 1" FPT Swivel (Water), 3/4" PVC Socket (Condensate) Connection, 1-Phase, 54-2/5" H x 25-3/5" W x 31-3/5" D Dimensions, 1,600 CFM, Direct Drive, Dual Capacity Scroll, 9" Diam x 7" W Blower Size, 1 HP (Blower Motor), Galvanized Steel (Cabinet), Copper (Coil Inner Tube), Steel (Coil Outer Tube), Vertical Upflow, 32" x 30" x 2" Filter Size, 2 Stage, 49,000 BTU/hr, 34.5 A (FLA), 39.8 A (MCA), 464.7 PSI (Working Water), 614.7 PSI (Working Refrigerant), 50-110 °F (Entering Air, Cooling), 40-80 °F (Entering Air, Heating), 30-120 °F (Entering Water), 60 Hz, 60 A Fuse Rating, Off White, Powder Coated (1,000 Hour Salt Spray Rated)
- Features a dual-capacity Copeland UltraTech scroll compressor for efficient, staged operation.
- Includes a 1 HP variable-speed ECM blower motor providing up to 1600 CFM.
- Achieves high energy efficiency ratings (EER 17.2-24.5).
- Utilizes environmentally preferred R-410A refrigerant.
- Constructed with a heavy-gauge galvanized steel cabinet and a corrosion-resistant powder coat finish.
- Designed for vertical upflow installation with right-hand return air.
- Accommodates a standard 2-inch MERV 11 filter (32" x 30").
- Operates on standard 208/230V, 1-phase, 60 Hz power.
