RectorSeal Goliath Furnace 96222 Secondary Drain Pan, 34" x 64" Size, 3/4" (Drain) Connection, -40-260 °F, UL 94-5VA Fire Rating, Dexelar Polymer, Black, Domestic
RectorSeal Goliath Furnace 96222 Secondary Drain Pan, 34" x 64" Size, 3/4" (Drain) Connection, -40-260 °F, UL 94-5VA Fire Rating, Dexelar Polymer, Black, Domestic
| Color | : | Black |
| Connection Type | : | 3/4" (Drain) |
| Depth | : | 7-1/2 in |
| Dimensions | : | 64-1/8" L x 34-1/8" W x 7-1/2" D |
| Domestic/Import | : | Domestic |
| Fire Rating | : | UL 94-5VA |
| Length | : | 64 in |
| Material | : | DexElar Polymer |
| Model | : | 96222 |
| Opening Size | : | 3/4" (Drain Connection) |
| Series | : | Goliath Furnace |
| Size | : | 34" x 64" |
| Specifications | : | 3/4 in Connection |
| Suitable For Use With | : | Air Handler or Furnace (with Coil) |
| Temperature Rating | : | -40-260 °F |
| Width | : | 34 in |
Goliath Furnace Series Secondary Drain Pans offer all the same benefits and features of our Goliath Series Secondary Drain Pans and are specifically designed for the unique clearance needs of furnace installations and piping requirements.Offer the benefits of Goliath Secondary Drain Pans but designed for clearance needs of furnace installations and pipes, 7" clearance for piping below furnace units, made with no seams/rolled edges of DexElar, a nearly indestructible advanced polymer
RectorSeal Secondary Drain Pan, Model: Goliath Furnace, 34" x 64" Size, 3/4" (Drain) Connection, -40-260 °F, UL 94-5VA Fire Rating, Dexelar Polymer, Black, Domestic
- Constructed from durable DexElar polymer for superior strength and impact resistance.
- One-piece, seamless design with rolled edges prevents cracks, splits, leaks, and rust.
- Withstands extreme temperatures from -40°F to 260°F.
- Self-extinguishing material meets UL 94-5VA flame retardant standards.
- Provides 7 inches of clearance for furnace piping and P-traps.
- Compatible with RectorSeal AG-4200 water sensor and AG-GFR vibration isolators.
