DiversiTech DTG Series FD-164-S Filter Drier, ODF Connection, 1/2" Connection Size, 16 Cu. In., 7.51 Tons (R-410A), 7.39 Tons (R-22), 20 Microns Micron Rating, All Common Refrigerants (CFC, HCFC, HFC, HFO), 714.7 PSI
DiversiTech DTG Series FD-164-S Filter Drier, ODF Connection, 1/2" Connection Size, 16 Cu. In., 7.51 Tons (R-410A), 7.39 Tons (R-22), 20 Microns Micron Rating, All Common Refrigerants (CFC, HCFC, HFC, HFO), 714.7 PSI
| Connection Type | : | ODF |
| Domestic/Import | : | Import |
| Finish | : | Painted |
| Flow Capacity | : | 7.51 tons (R-410A), 7.39 tons (R-22) |
| Material | : | Steel (Casing), Molecular Sieve/Active Alumina (Desiccant Blend) |
| Micron Rating | : | 20 microns |
| Model | : | FD-164-S |
| Pressure Rating | : | 714.7 PSI |
| Refrigerant Type | : | All Common Refrigerants (CFC, HCFC, HFC, HFO) |
| Series | : | DTG Series |
| Size | : | 1/2 " |
| Suitable For Use With | : | All Common HCFC and HFC Refrigerants |
| Temperature Rating | : | -22-131 °F (Ambient), -22-248 °F (Medium Ts) |
| Volume | : | 16 cu. in. |
This Sanhua filter-drier serves as a system protector for optimum performance and efficiency, effectively stopping contaminants, moisture, and acid. Engineered with world-class technology and premium materials, it filters solid particles, adsorbs moisture, and removes acid to ensure superior system protection.
DiversiTech Filter Drier, Model: DTG Series, ODF Connection, 1/2" Connection Size, 16 Cu. In., 7.51 Tons (R-410A), 7.39 Tons (R-22), 20 Microns Micron Rating, All Common Refrigerants (CFC, HCFC, HFC, HFO), 714.7 PSI, -22-131 °F (Ambient), -22-248 °F (Medium Ts), Steel (Casing), Molecular Sieve/Active Alumina (Desiccant Blend), Painted, Import
- Effectively filters contaminants down to 20 microns.
- Features a desiccant blend of 80% molecular sieve and 20% active alumina to adsorb moisture and remove acid.
- Core is secured by fiberglass pads and a 100 mesh metal support screen at the outlet for reliable filtration.
- Compatible with all common CFC, HCFC, HFC, and HFO refrigerants.
- Rated for a maximum operating pressure of 714.7 PSI.
- Exterior paint provides corrosion resistance, tested to surpass 500-hour salt spray conditions.
- Certified for use with A2L refrigerants.
